SUPER COMBO SET DI 4 MOTORI + ACCESSORI!!!
1) No. of Cells: 2 - 3 Li-Poly 6 - 10 NiCd/NiMH
2) Kv: 1000 RPM/V
3) Max Efficiency: 80%
4) Max Efficiency Current: 4 - 10A (>75%)
5) No Load Current: 0.5A @10V
6) Resistance: 0.090 ohms
7) Max Current: 13A for 60S
8) Max Watts: 150W
9) Size: 28 mm dia x 28 mm bell length
10) Shaft Diameter: 3.2 mm
11) Poles: 14
12) Propeller Volts (V) Amps (A) Thrust (g/oz) Power (W) RPM Pitch Speed
APC 10x5 E 10.85V 13.05A 26.8 oz 141.6W 7723 36.6 mph
APC 9x6 E 10.87V 12.4A 23.1 oz 134.8W 7920 45 mph
MA 9x6 10.87V 13.6A 19.5 oz 147.8W 7620 43.3 mph
13) An small yet powerful motor for planes up to 800 grams (28 oz) using 3 li-poly cells. We suggest propping for around 140 watts continuous power with short bursts up to 180 watts. An excellent higher-powered replacement for geared Speed 400-480 motors in slow-flying or 3D planes that require a larger 10" propeller. Use on sailplanes up to 28 oz, trainers up to 25 oz, aerobatic aircraft up to 18 oz and 3D airplanes up to 15 oz. Recommended prop is 10 x 5 on 3 li-poly cells.
14) The motor features a 3.2mm hardened steel shaft, dual ball bearings, and has 3.5mm gold spring male connectors already attached and includes 3 female connectors for your speed control. Now includes collet type prop adapter and radial motor mount. Mounting holes have 16mm and 19mm spacing on centers and are tapped for 3mm (M3) screws.
15) Including: 4 set 2212 1000KV Brushless Outrunner Motor with Mounts,screws,propeller adapter.
16) Similar to Welgard A2212-13, AXI Gold A2212/26, Welgard C2830-12, E-Flite Park 400.
