12 Channel 900Mhz Tx/Rx video system with CCD camera.
A high-power tx system for long range, clear video.
*This version features 520-line PAL
Unlike other generic systems, we have produced a wiring loom and included it with the camera so that the Tx and camera will be compatible and on the same voltage.
If you buy your camera and Tx seperately the plug polarity and voltages may be very different.
Included.
1 x SONY CCD 1/3inch Camera
1 x 900Mhz 8 channel Video Transmitter (800mW)
1 x 900Mhz 12 channel Video Receiver
Camera spec.
CCD sensor type:1/3 color SONY CCD
Pixel;
NTSC: 510(H)*492(V)
PAL: 520(H)*582(V) (included)
Scanning system: Interlaced scanning
Synchronization: System:Inter
Horizontal resolution: 420TV line
Minimum Illumination 0.01LUX/F1.2
DSP+CCD: CXD3142R+405AK
S/N Ratio: 48dB
Gamma Modification: 0.45
White balance: Auto
Auto backlight compensation: Auto
Lens: 3.6MM
Audio: No
Input voltage: 9~12.6V
Electric current 80MA
Electronic Shutter: 1/50 (60) ~ 1/100,000s
Video output: 1.0VP-P composite video
Operation Temp.: -20~50
Size: 38*38mm
Flight time: Approx 60min/100mah 3S
Non disp.
