The ESC with the BIGGEST BEC
Castle's new Talon 90 ESC sports a BEC designed for today's servos, pumping out up to 20 amps peak power and 9 amps of continuous power to keep even the hungriest servos happy.
Designed for Helis
Talon 90 is ideal for helicopters drawing 2,000 watts on 6S. It's a great fit for extreme 500 and 550 class helis and sport (6S) 600 setups. Of course, Talon offers Castle's industry-leading helicopter functions, such as the unbelievable direct entry governor mode. Simply type in the desired RPM using a Castle Link USB adapter (sold separately) and the free Castle Link GUI running on a Windows PC!
Great for Fixed Wing
The Talon 90 is perfect for aerobats up to 10 pounds and scale ships up to 20 pounds. The innovative case ensures cooling in even the toughest mounting locations.
Fearture:
●Supporting 6S(25.2v)brushless motor. Max current : 90A
●Max. BEC output :20 Amp, Continuous: 9 Amp
●Users can adjust and choose the BEC output voltage as 6V or 8V by software
●Ready to fly out of the bag, but users can tap into serious computing capabilities by connecting them to Castle Link software using a Castle Link or upcoming Field Link programming card.
●Comprehensive heli feature set, including direct entry governor mode, autorotation with bailout, and soft start capabilities to protect your gearing (see the screenshot on the right for more details).
●Opto isolated throttle cable helps reduce radio interference.
●Input voltage: 3S to 6S (12V - 25.2V)
●Surge current : 90 Amps
●Surge current : 140Amps(5sec) (with proper air flow and outer temperature is lower than 70°C)
●BEC output voltage: Continuous current 20A; Burst current 9A
●Supporting motor types:2 poles to 10+poles in/outrunner brushless motors
●Max Supporting input voltage:25.2v(6s Li-Po/18 cells Nicad/NiMH)
●Size:80X43X18mm
●Weight:84.5g(With wires)
