CNC AL and CF Main Frame Set (SILVER) - Trex

1. Description:
- Precision CNC Main Frame is designed from Aluminum alloy, Carbon Fiber and Delrin material to get more strength.
Special Features:
- Compatible and replaceable for Plastic Main Frame.
- There are two pieces carbon fiber to support Tail system better and more stronger.
- There are two screws at Landing Gear Holder for supporting landing gear better.
- Maximum can use Main Motor diameter 15.5mm.
- Adjustable Main Motor to get better gearmesh.
- Aluminum Motor Mount as heatsink with large contact area help motor increase efficiency and cooler.
- Optimized for weight and durability.

2. Usage:
- Use for Trex 150 DFC.

3. Weight:
- Stock Frame: 4.87(g) = 0.17(oz).
- CNC AL and CF Main Frame Set: 4.69(g) = 0.16(oz). Lighter weight than Stock Frame: 0.18(g).

4. Included:
- CNC AL and CF Main Frame SILVER (1set).

* Hardware:
- (SKU: MR63-2) 3x6x2 Radial Bearing (2pcs).
- (SKU: M1x2PH-10) M1x2mm Pan Head Screw (8pcs).
- (SKU: M1x3SPH-10) M1x3mm Self Tapping Pan Head Screw (7pcs).
- (SKU: M1.2x2PH-10) M1.2x2mm Pan Head Screw (1pcs).
- (SKU: M1.2x3PH-10) M1.2x3mm Pan Head Screw (2pcs).
- (SKU: M1.2x6PH-10) M1.2x6mm Pan Head Screw
