The HK4B6 Balance Charger features 4 port charging that allows you to charge a combination of 4 batteries at once. Each charging port features an independent charging circuit that allows you to charge NiXX, LiXX or pB batteries, This means, for example, you could charge 2 Lipoly flight packs, a transmitter pack and a glow plug driver all at the same time!
The HK4B6 includes an assortment of adapters and accessories including balance boards for Jst XH, TP, EH and PQ batteries. With 4 ports and a host of included charging accessories this charger could well become the most versatile battery charger in your hanger!
Features.
Microprocessor controlled
Delta-peak sensitivity (NiMH/NiCd)
Individual cell balancing
Li-ion, LiPo and LiFe capable
Ni-Cd and NiMH capable
Large range of charge currents
Store function, allows safe storage current
Time limit function
Input voltage monitoring. (Protects car batteries at the field)
Data storage (Store up to 5 packs in memory)
Battery break in and cycling.
Spec.
Operating Voltage: 11~18v DC
Charge power: 50w x 4
Discharge Power: 5w x 4
Discharge Current: 300mA
Cell count: 1~15 NiXX, 1~6 LiXX, 1~10 pB (Lead Acid)
NiXX Charge termination: Auto, Negative Delta peak
LiXX Charge termination: Auto, Voltage dependent, CC-CV
Non disp.
