The new Easy combo from MultiStar and Afro, matching the most popular combinations into one easy package.
The "Baby Beast" combo matches the legendary MultiStar 2206 V2 CW/CCW motors with the 12A V3 Afro ESCs for a perfect 220~300mm quadcopter power combo. No more guess work, no more waiting for stock of all the combo parts.
The Afro ESC boasts high efficiency, all N-channel MOSFET design, jitter-free hardware PWM input, and smooth power response, the Afro ESC series are set to change the expectations of multirotor pilots around the globe. The Afro ESC series are shipped with multirotor specific SimonK software preloaded, no need to reflash. For added convenience the Turnigy USB linker can be used via the PWM signal lead for any future software updates eliminating the need for complicated flashing jigs or the need to cut open the heat shrink.
The 2206-2150KV V2 MultiStar nicknamed the “Baby Beast”, is the monster motor for the small 250 class quadcopters! Designed for 5 or 6 inch props, this motor has power on tap, and ready for your fully loaded 250. The motor has been beefed up in all the right places for FPV durability, with 3.17mm center shaft, 11mm prop flange and a 5mm prop shaft, there is no need to worry about the occasional tree in the way. It's fitted with shimmed and pre-loaded bearings and high grade silicon wires. If you're looking for more power, durability and value for your sub-300mm multirotor, think…. MultiStar 2206 the Baby Beast
MultiStar is simplifying the world of Multi-Rotors with their purpose built product line and taking the guess work out of your setup.
Specs (Motor):
KV(RPM/V): 2150
Lipo cells: 2~3s
Max Power: 120w
Max Amps: 10A
Dimensions(Dia.xL): 27 x 17mm
Motor Shaft: 3.17mm (5mm prop shaft) 2CW 2CCW
Prop shaft: 5mm or Direct mount with 9mm center to center
Weight: 30g
Bolt hole spacing: 16mm * 19mm
Connectors: 2mm bullet
Specs (Afro 12A ESC):
Current Draw: 12A Continuous
Voltage Range: 2-4s Lipoly
BEC: 0.5A Linear 5.0v
Input Freq: 1KHz
Firmware: afro_nfet.hex
Discharge wire/plugs: 20AWG/male 2mm
Motor wire/plugs: 20AWG/female 2mm
Weight: 10g (Included wire, plug, heat shrink)
Size: 25 x 20 x 6mm
Royalties paid on each unit sold to SimonK and Hamasaki for their design work, without which the Afro ESC would never have been born, thanks guys!
*Note: lower mounting screw length is critical to check. The lowered housing was reduced in height to make a nice compact 2206, the tradeoff is the motor winding is closer to the bottom, so overly long mounting screws could potentially contact the windings and damage the motor.
