SAB GOBLIN KRAKEN 580

« Features »

• AIRFRAME weight: 1760gr ( with blades, no battery, no electronics )
• Main blade length: 550mm to 600mm
• Tail blade length: 95 to 105 mm
• Main rotor diameter: 1270 mm (with 570 mm blades included)
• Tail rotor diameter: 260 mm (with 95 mm tail blades included)
• Cyclic Servos: mini size 35 mm (standard size 40mm option )
• Tail Servo: standard size 40mm.
• Main Rotor ratio : 11.5 to 8.6 :1 ( 22T included: 9.4:1)
• Tail Rotor ratio : 5.3-4.9:1 ( 23T included: 4.9:1 )
• Typical motor : 4025 series, 6S 1000-1200 Kv, 12S 500-600 Kv
• Typical speed controller: 6S 120-140 A, 12S 100-130A
• Battery size: 6S 5000/5800 mAh, 12S 2600/3200 mAh

« Additional Information »

• we highlight the interesting feature of being able to use blades up to 600 mm in length.
• the Kraken 580 works perfectly with cyclic mini-servos (torque over 8 Kg-cm).
  Kit includes supports for mini-servo.
• If the customer wants to use servos with a standard size of 40 mm,
  he has to buy P/N H1217-S & H1207-S as an option.
• battery trays are H1102-S
• motor pulleys are H0015-xx-S series
• min motor shaft length is 26mm ( it is suggested 6 mm diameter )

« Kit includes »

• SAB Goblin KRAKEN 580 Heli Kit
• SAB Carbon 570 mm Main Blades
• SAB Carbon 9+5 mm Tail Blades
• Motor Pulley 22Z
• Manual
•
