Introduction:
Brushless Gimbal is the next generation technology for high quality aerial photography. Senrigan GP-55 Brushless Gimbal is driven directly with two Brushless Motors for 3-axis movement roll, tilt and yaw without gears or belts. The main advantages of this design compared to traditional actuators (servos) are the Brushless Gimbals have no backlash in the gear/belt, and it provides the instantaneous response to the disturbance. Due to lack of gears/ belts, this new Brushless Gimbal is extrenely easy to install and with low weight which is perfect for aerial activities. The lower the weight, the longer the flying time you can achieve.
Differ than others, the motors and Gimbal Controller of Senrigan GP-55 Brushless Gimbal have been well test and tuned of the PID parameter for NEX N5/ N7 Cameras in the factory before selling. So no worries about the setting or PID tuning of the Brushless Gimbal. However, it is easy and convenience to change the setting (setup Follow Mode etc.) of GP-55 since it is using the famous Gimbal Software called Alexmos which is one of the most user friendly and functional software for brushless gimbals.
Features:
-Direct drive of Brushless Motors for 3-axis including Roll, Tilt and Yaw axis.
-Simple and strong Mechanism Design
-Made of CNC Metal Parts and full Carbon Fiber Frames which is super light and strong.
-Super Steady Performance with high quality Rubber Tension Damper Balls.
-High Quality 3-axis Alexmos Brushless Gimbal Controller with High Quality CNC Casing.
-Well tested and PID parameter tuned by the factory for NEX N5/ N7/ Similar size cameras.
-Controllable Tilt and Yaw Axis Movement.
-Suitable for Alware Cyclone X8/ DJI S800 multicopters
-Easy to install and use.
-Ligh in weight.
Specification:
-Movement: 3-axis, Roll, Tilt and Yaw
-Tilt control: Up 45°, Down 90°
-Yaw control: ±360° (360° mechanic continuous rotation)
-Working Voltage: 2S 7.4V Lipo JST Connector (default)
-Brushless Gimbal Controller Weight: 49g (With CNC case and wires)
-IMU Weight: 4.0g (With wires)
-Brushless Gimbal Motor Weight: 94g /Pcs
-Brushless Gimbal with Controller: 683g (Without Camera)
Included:
1x Senrigan GP-55 Brushless Gimbal
1x 3-axis Alexmos Brushless Gimbal Controller with High Quality CNC Casing.
1x IMU Unit
12x High Quality Rubber Damper Balls
1x Tilt and Yaw Controlling Connector
(Please be noted that Camera, Aircraft and Battery are not included.)
