Dimension: 43mm x 37mm, 62mm(with shaft)
Weight: 136g (kv750) (not including connectors)
Diameter of shaft:âF5mm
Length of front shaft:âF19.3mm
Lamination thickness: .2mm
Magnet type: 45SH
Max performance;
Voltage: 2-3S
Max current:
30~45A/20S Prop: 11x5.5~13x4
Thrust:
1730~2150g
Power:
800W For 1500~2000g 3D model airplane.
Download data files;
TURNIGY MOTOR DATA
