Neuerungen:
"T" for Telemetry. following protocols are currently compatible:
- Mikado VBAR soon
- Futaba, FR-Sky & Spectrum via S32 / JLOG from R2Prototyping
- Graupner HoTT V4
- Jeti ExBUS
- Multiplex Sensor BUS V2
- YGE-protocol for different telemetry-connections
- more protocols follow soon
Highlights:
- Update capable (optional USB-Adapter available)
- entirely overhauled hard- und software (32-bit)
- the PWM-frequency will be set automatically to the requirements of the motor
- Current-limitation
- 2 to 6S LiPo
- super smooth sinus-startup
- adjustable HV-BEC from 5,5 to 9V
- high BEC-current rating: 8A permanent / 18A peak
- dimensions in mm: 64 x 26 x 9
- weight with / without cables: 30g / 45g
- basic settings via mode-setup
- BEC- and Telemetry-settings, as well as additional parameters adjustable via PC-Software -
(optional USB-adapter available)
Specs:
- The specified current is the maximum continuous full power current
- 2 to 6s LiPo, incl under voltage protection by power reduction
- BEC: 5,5-8,4V - 8A Current / 18A Peak
- Current limiting
- Disconnectable under voltage detection
- Electronic speed control (Governor- mode)
- Soft start
- Active free-wheel, allowing unlimited part load operation.
- Automatic or 6 step adjustable timing
- Adjustable EMK brake
- F3A(Acro brake (brake force control infinitely adjustable)
- Frequency: 16 to 32 kHz
- Speed limit: 240.000 rpm (2- Poles)
- Temperature and overload warning
- Anti- flash: decreases the closing spark (65LVT)
- Basic -Programming with mode programming
- Fine adjustment and selection of telemetry log with the PC Setup
- Suitable USB-adapter optionally available
