ZERO TECH continue to push the boundaries with the YS-S4 autopilot system. The V3 version has all new firmware, new attitude stabilization algorithm and optimized hardware structure, all in all the YS-S4 provides better all round flight performance than its predecessor.
The innovative mini all-in-one design simplifies the installation process and also saves space and weight. With its built-in inner damping, controllers, 3-axis gyroscope, 3-axis accelerometer and barometer, the YS-S4 V3 can measure flying altitude and attitude for autopilot / automatic control precisely. Its compact size makes it extremely simple to install to any multitotor frame.
Features:
• Multiple flight control Mode, manual Stabilization Mode, GPS attitude mode (auto hover / auto go home / landing),
• Intelligent motor arm/disarm features
• Built-in vibration damper
• Supports camera gimbal stabilization
• Online firmware update
• Fail Safe (auto hover -> go home -> auto land)
• Low voltage vibration alert (WIFI module required)
• Support smart phone control (WIFI module required)
• Remote gain adjustment (WIFI module required)
• Support WIFI function (WIFI module required)
• Easy to see LEDs to indicate status
Specs:
Hovering position accuracy (GPS mode): Vertical: ± 1m; Horizontal: ± 2m
Max Level Speed: < 10.2m/s
Max Tilt Angle: 35°C
Max Ascent/Descent Speed: <5m/s
Map: Google 3-D GIS
Supported Multi Rotor Types: Quad-Rotor: +4, x4; Hexa-Rotor +6, x6
Supported ESC Output: 400Hz refresh frequency PWM
Recommended Battery: 3S~6S LiPo
Power Consumption: 1W
Operating Temperature: -5°C to +60°C
Weight: Main controller 32g, GPS 37g
Size: Main controller 46 x 42 x 19mm, GPS 55 x 11mm
LED: 18 x 18 x 7mm
